General description:
WZ series is suitable for conveying at a temperature of -20c to +80c, Viscosity of not more than 5 E without solid particles, volatile, easy gasification of seawater and freshwater. It can be used for ship,petroleum,chemical industry,printing and dyeing industry, hotels, villas and high-rise living water for boiler.This type pump has the advantages of small volume,light weight,strong self-absorption,can be equipped with motor,gasoline engine, diesel engine as power.
Tech Parameter:
|
Type
|
Suc'Head |
Capacity |
Head |
Power |
|
(m) |
(m3/h) |
m |
kw |
|
|
|
|
50hz/1450rpm |
||
|
20WZ-14X2 |
7.5 |
1.44 |
28 |
0.75 |
|
20WZ-14X3 |
7.5 |
1.44 |
42 |
1.1 |
|
20WZ-14X4 |
7.5 |
1.44 |
56 |
1.5 |
|
25WZ-16X2 |
7 |
2.88 |
32 |
1.5 |
|
25WZ-16X3 |
7 |
2.88 |
48 |
2.2 |
|
25WZ-16X4 |
7 |
2.88 |
64 |
3 |
|
32WZ-18X2 |
6.5 |
5.4 |
36 |
3 |
|
32WZ-18X3 |
6.5 |
5.4 |
54 |
4 |
|
32WZ-18X4 |
6.5 |
5.4 |
72 |
5.5 |
|
40WZ-28X2 |
6 |
9 |
56 |
7.5 |
|
40WZ-28X3 |
6 |
9 |
84 |
11 |
|
40WZ-28X4 |
6 |
9 |
112 |
15 |
|
50WZ-32X2 |
5.5 |
14.4 |
64 |
11 |
|
50WZ-32X3 |
5.5 |
14.4 |
96 |
18.5 |
|
65WZ-36X2 |
5 |
21.6 |
72 |
22 |
|
65WZ-36X3 |
5 |
21.6 |
108 |
20 |
