General Description:
Stainless steel vertical windlass. Available in high or low profile, with different drives and recommended for boats up to 50m. Windlass can use chains up to 18mm with stud link in diameter.
Tech Parameter:
|
Model
|
Max.pressure |
Max.pull |
Flow rate |
Working load |
Max.Line speed |
|
(bar) |
(Kg) |
(L/min) |
(Kg) |
(m/min) |
|
|
YDHP1011H |
200 |
1800 |
20-40 |
1200 |
10-20m/min |
|
YDHP1012H |
200 |
2000 |
25-50 |
1500 |
10-20m/min |
|
YDHP1013H |
200 |
2600 |
28-60 |
2000 |
10-15m/min |
|
YDHP1014H |
200 |
3500 |
28-60 |
2800 |
8-15m/min |
