The inclined belt skimmer is mainly composed of the hydraulic power station, skimmer head (the main unit), the hydraulic oil hose, oil pipe and other parts.
The main unit of the skimmer can recovery the oil spill by pushing the oil spills into the water and then make it go through the oil collecting channel. One end of the inclined belt is above the water surface while another end is below the water surface. It is driven by the hydraulic motor to push the oil spill under the water, then the oil spill would emerge from the water and then into oil collecting channel.
Hydraulic power pack works under the diesel engine or electrical machine which drives hydraulic oil pump and conveying oil pump. The main unit is composed of the inclined belt, the oil collecting channel, frame, buoy, the hydraulic oil hose, oil pipe and other parts.
It is not only suitable for harbors, wharfs, gulf, rivers, lakes and other semi-enclosed waters, but also for open seas, offshore and other open water.
|
Model/Parameter |
XDJ-10 |
XDJ-20 |
XDJ-30 |
XDJ-40 |
XDJ-60 |
XDJ-100 |
XDJ-200 |
|
Max, skimming rate(m³/h) |
10 |
20 |
30 |
40 |
60 |
100 |
200 |
|
Working pressure(MPa) |
3-6 |
3-6 |
5-6 |
5-6 |
5-8 |
5-10 |
8-10 |
|
drive power(diesel engine or explosion-proof motor)KW |
6.3/4 |
14.5/7.5 |
14.5/11 |
21/15 |
21/18.5 |
29/22 |
56/45 |
|
suction head of oil suction pump (m) |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
|
Lift of oil suction pump（m） |
15 |
30 |
30 |
30 |
30 |
30 |
30 |
|
Number of diversion booms (piece) |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
|
Length of diversion booms(m) |
6 |
6 |
6 |
10 |
10 |
10 |
10 |
|
Length of boom arm (m) |
6 |
6 |
6 |
10 |
10 |
10 |
10 |
