General Description:
The launching appliance is a special equipment for lowering and recovering work boat and rescue boat. The design of the launching appliance conforms to the requirements of the “1974 SLOAS [MSC.47(66)] and International LSA Code [MSC.48(66)]. The inspections and tests of the appliance conforms to the IMO Resolutions MSC.81(70).
The launching appliance is capable of launching the fully laden work boat /rescue boat to water surface under adverse condition of a trim of up to 10 degree and a list of up to 20 degree and recovering work boat /rescue boat with rating persons to stowed position.
Approval by CCS, BV, ABS, DNV-GL,RINA and etc.
Tech Parameter:
|
Type |
SWL kn |
Hoisting speed m/min |
Lowering spped m/min |
Swing time Second |
List+Trim Degree |
Boat type |
|
FR15 |
15 |
≥18/48 |
0--50 |
0--30 |
20+10 |
4-5.5m |
|
FR27 |
27 |
≥18/48 |
0--50 |
0--30 |
20+10 |
6-7.5m |
|
FR35 |
35 |
≥18/48 |
0--50 |
0--30 |
20+10 |
8-9m |
|
FR125 |
125 |
≥18/48 |
0--50 |
0--30 |
20+10 |
8-9m |
